| Capacity |
11KVA/11KW |
| Maximum PV Input Power |
11KW |
| Parallel Capability |
NO |
| Lithium Battery Activation |
YES(By PV or Utility) |
| Lithium Battery Communication |
YES(RS485) |
| Built-in WiFi |
Optional |
| Nominal Voltage |
230VAC |
| Acceptable Voltage Range |
170-280VAC(For personal Computer);90-280VAC(For Home Appliances) |
| Frequency |
50/60 Hz(Auto sensing) |
| Nominal Voltage |
220/230/240VAC |
| Surge Power |
22000VA |
| Frequency |
50/60Hz |
| Waveform |
Pure Sine wave |
| Transfer Time |
10ms(For personal Computer);20ms(For Home Appliances) |
| Peak Efficiency |
94% |
| Overload Protection |
5s@>=140%load;10s@110%~140%load |
| Admissible Power Factor |
0.6~1(inductive or capacitive) |
| Battery Voltage |
48VDC |
| Maximum Discharge Current |
220A |
| Floating Charge Voltage |
54VDC |
| OverCharge Protection |
63VDC |
| Charging Method |
CC/CV |
| Solar Charger TYPE |
MPPT |
| Max.PV Array Power |
5500W*2 |
| Max.PV Array Open Circuit Voltage |
500VDC |
| PV Array MPPT Voltage Range |
60VDC~500VDC |
| Max.Solar Input Current |
18A*2 |
| Max.Solar Charge Current |
160A |
| Max.AC Charge Current |
120A |
| Max.Charge Current |
160A |
| Dimensions,D×W×H |
540*403*122mm |
| Net Weight |
14.8kg |
| Communication Interface |
RS232/RS485/DRY CONTACT |
| LCD |
YES |
| Operating Temperature Range |
(-10’℃ to 55°℃) |
| Storage temperature |
(-15°℃~60°℃) |
| Humidity |
5%to 95%Relative Humidity(Non-condensing) |
| Ingress Protection |
IP21 |
